DIN HV PSU

£41.00 excl. VAT

This unit is a high voltage 340VDC max adjustable DIN rail power supply.

10 in stock

SKU: PSU-3843-HV_DINPSU-1 Categories: , , , , Tag:

Description

This board offers a High voltage DC drive for specialized sensors/ other equipment.

Features:

  1. Adds a user-settable +75 to +340V DC supply from the industry-standard +24VDC power input.
  2. 6Watt  (18mA at 340V) output capability.
  3. Dimensions: approx. 82 x 22 x 115 mm (L x W x H).
  4. Compatible with Industry-standard DIN rail mounting.
  5. Convenient Pluggable 6 way screw terminal connector.
  6. Made in England.

Additional information

Weight 0.092 kg
Dimensions 8.2 × 2.2 × 11.5 cm
